Product Specific Attributes
HiPath 5000 V7
Issue: 18
th
April 2007 Page - 10 -
Siemens Enterprise Communications GmbH & Co KG
2.1.2.2 optiPoint 410/420 SIP V5 R0
Application Function Type A-Prot.
M-
Prot.
T-Prot.
D-
Ports
A-
Ports
Remarks
OAM (oP410 SIP) Administration of optiPoint SIP devices
.
DHCP-Client (op410)
Server of "Dynamic
Host Configuration
Protocol"
client DHCP --- UDP 68 Def: DHCP Client Port
.
DHCP-Server (oP410)
Server of "Dynamic
Host Configuration
Protocol"
server DHCP --- UDP 67 Def: DHCP Server Port
.
DLS Workpoint
Interface (client sided)
workpoint sided DLS
Communication
interface workpoints
client WPIP HTTPS TCP 18443
0 -
65535
Def: DLS: Communication interface
workpoints – DLS
. DNS DNS relay server DNS --- TCP_UDP 53 Def: DNS
.
FTP_Server_Control
(oP410) FTP-Server
server FTP --- TCP 21 Def: FTP-Server Control Port
.
HTTPS_Server
(Phones) Secure
Embedded Web
Server
server HTTP --- TCP 443
0 -
65535
Def: HTTPS
.
HTTP_Server
(Phones) Web
Interface
server TFTP --- TCP 8085
0 -
65535
Def: HTTP optiPoints, HG1500
.
IP-Config (Phones) IP
Configuration Services
server *proprietary* --- UDP 5100
.
SNMP (SET/GET)
(Phones) SNMP
SET/GET-Functionality
server SNMP --- UDP 161 Def: SNMP (Set/Get)
.
SNMP Trap (oP410)
SNMP Trap function
client SNMP --- UDP
161
162
Def: SNMP Trap (oP410)
.
SNTP (oP410) Simple
Network Time Protocol
server SNTP --- UDP 123 Def: SNTP
.
SNTP heartbeat
(oP410) Simple
Network Time Protocol
server SNTP --- UDP 580
QoS Data Collection Unit (QCU) phones Send QoS reports
.
QCU client 12010
Client application
which sends QDC data
to the QCU
client SNMP --- UDP 12010
0 -
65535
Def: QCU receiving Port
SIP payload transport (op410 SIP) Session Inition Protocol (SIP) payload
.
SIP Payload Transport
(oP410) active Voice
over IP: Transmission
of Payload
client RTP_RTCP --- UDP
5004 -
5027
0 -
65534
Def: Port 5004 .. 5006 for normal usage.
For every line-key you have to add two
channels. The maximum of line keys are
10 -->. For this the maximum range of
5004 .. 5027 is valid
Adm: even port number only
.
SIP Payload Transport
(oP410) passive Voice
over IP: Transmission
of Payload
server RTP_RTCP --- UDP
5004 -
5027
0 -
65534
Def: Port 5004 .. 5006 for normal usage.
For every line-key you have to add two
channels. The maximum of line keys are
10 -->. For this the maximum range of
5004 .. 5027 is valid
Adm: even port number only
SIP Signalling (op410 SIP) Session Inition Protocol (SIP) signaling
.
SIP Signaling (WL2-
Phone) SIP over TLS
client SIP ---
TCP -
TLS
5061 Def: SIP
