boards.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
3-23
Nur für den internen Gebrauch Boards for HiPath 3000
Central Board
V.24 interface assignment
LAN connector assignment
CBCC S30810-Q2935-A301: The Ethernet LAN interface is provided by the optional LIM sub-
board.
Table 3-6 CBCC - V.24 Interface Assignment (SUB-D Plug)
X18, Pin Signal Description
1 – Not used
2 RxD A Receive data, channel A
3 TxD A Transmit data, channel A
4 – Not used
5 0 V Ground
6 – Not used
7 RTS A Request to send, channel A
8 CTS A Clear to send, channel A
9 – Not used
Table 3-7 CBCC - LAN Connector Assignment (RJ45 Jack)
Pin Signal Description
1 Tx + Transmit +
2 Tx – Transmit –
3Rx+Receive+
4 – Not used
5 – Not used
6Rx–Receive–
7 – Not used
8 – Not used
