Central Board
Default numbering plan when using CBCC in HiPath 3550
Table 3-8 Default numbering plan when using CBCC in HiPath 3550
Station Int. call no. DID no. Port
U
P0/E
host
(master)
100 100 U
P0/E
1
101 101 U
P0/E
2
102 102 U
P0/E
3
103 103 U
P0/E
4
104 104 U
P0/E
5
105 105 U
P0/E
6
106 106 U
P0/E
7
107 107 U
P0/E
8
U
P0/E
client
(slave)
500 500 U
P0/E
1
501 501 U
P0/E
2
502 502 U
P0/E
3
503 503 U
P0/E
4
504 504 U
P0/E
5
505 505 U
P0/E
6
506 506 U
P0/E
7
507 507 U
P0/E
8
T/R 108 108 T/R 1
109 109 T/R 2
110 110 T/R 3
111 111 T/R 3
EVM 112 112 EVM-1
113 113 EVM-2
Line Code Port
S
0
CO PP
7801 S
0
1-1
7802 S
0
1-2
7803 S
0
2-1
7804 S
0
2-2
