Central Board
Part numbers
● LUNA2: S30122-K7686-A1, S30122-K7686-M1
For production-related reasons, two different LUNA2 modules with the same functions are
used. Technically identical, the two models have minor mechanical differences and are ful-
ly compatible with each other.
● Battery pack 4 x 12V/7 Ah: S30122-K5950-Y200
Weight (including batteries): 14.1 kg
Dimensions (length x width x height): 280 mm x 160 mm x 140 mm
(the connection cable for LUNA2 is part of the battery pack)
● Power Cabinet PB3000 (see Page 9-6)
Technical Specifications
● Nominal voltage range: 110 Vac - 240 Vac
● Nominal frequency: 50 Hz - 60 Hz
● Output voltage (battery charging voltage, if a LUNA2 is used as a battery charger): –54.7
VDC; –53.5 VDC (for gel cell batteries, currently not released)
● Output current (battery charge current, if a LUNA2 is used as a battery charger): max. 2 A
● Bridging times
Table 3-22 lists the maximum possible bridging times (emergency battery operation in case
of power failure) with 48-V/7-Ah battery pack (S30122-K5950-Y200), and Powerbox
PB3000 (S30177-U773-X).
Table 3-22 LUNA2 - Bridging Times with 48-V/7-Ah Battery Pack, and Powerbox
PB3000
System Power supply unit Load levels Maximum bridg-
ing time
HiPath 3800 2 x LUNA2 per system cabinet as
PSU
1 x LUNA2 per system cabinet as
battery charger
1 x battery pack 48 V/7 Ah per sys-
tem cabinet
60 % nominal
load
25 min
HiPath 3800 2 x LUNA2 per system cabinet as
PSU
Powerbox PB3000 for each system
with 1 x LUNA2 as battery charger
and 4 x 12-V/7-Ah batteries
60 % nominal
load
25 min
