Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-76 HiPath 3000/5000 V9, Service documentation
boards.fm
Central Board
Diagram of UPSC-DR
Measurement conditions:
● All measurements were performed at a room temperature of approximately 23 °C
(73.4 °F).
● The batteries were fully charged when the measurement was started.
Figure 3-26 UPSC-DR (S30122-K7373-M900)
Table 3-28 UPSC-DR - Bridging Times with four Batteries V39113-W5123-E891 (4 x
12-V/7-Ah Batteries) and Powerbox PB3000
System Power supply unit Load levels Maximum bridg-
ing time
LED, green
LED, yellow
