Central Board
Technical Specifications
● Nominal voltage range: 100 VAC - 240 VAC
● Nominal frequency: 50 Hz - 60 Hz
● Ring voltage generator 75 Vac, 20/25/50 Hz
● Partial voltages: +5 VDC, -48 V
● Battery charger: 4 x 12 V (40,8 V-55,2 V)
● Power consumption: 180 W
● Bridging times
Table 3-28 lists the maximum possible bridging times (emergency battery operation in case
of power failure) with four batteries (4 x 12-V/7-Ah batteries) and Powerbox PB3000
(S30177-U773-X), depending on the system.
7
Danger
Do not use 24-V batteries (S30122-K5403-X) in conjunction with UPSC-DR as an
explosive gas (hydrogen + oxygen) escapes when the battery is overloaded.
Table 3-28 UPSC-DR - Bridging Times with four Batteries V39113-W5123-E891 (4 x
12-V/7-Ah Batteries) and Powerbox PB3000
System Power supply unit Load levels Maximum bridg-
ing time
HiPath 3300 UPSC-DR
4 x 12-V/7-Ah batter-
ies
Normal output load =
5 V: 3 A; –48 V: 0.5 A;
ringing approx. 2 VA
3 h
HiPath 3300 UPSC-DR
Powerbox PB3000
with 1 x LUNA2 and 4
x 12-V/7-Ah batteries
Normal output load =
5 V: 3 A; –48 V: 0.5 A;
ringing approx. 2 VA
3 h
HiPath 3500 UPSC-DR
4 x 12-V/7-Ah batter-
ies
Normal output load 100 % =
5 V: 8 A; –48 V: 1.1 A;
ringing approx. 4 VA
1 h 30 min
HiPath 3500 UPSC-DR
4 x 12-V/7-Ah batter-
ies
Normal output load 60 % =
5 V: 4.8 A; –48 V: 0.66 A;
ringing approx. 2 VA
2 h 20 min
HiPath 3500 UPSC-DR
Powerbox PB3000
with 1 x LUNA2 and 4
x 12-V/7-Ah batteries
Normal output load 100 % =
5 V: 8 A; –48 V: 1.1 A;
ringing approx. 4 VA
1 h 30 min
