Boards for HiPath 3000 Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
3-94 HiPath 3000/5000 V9, Service documentation
boards.fm
Peripheral boards
Assigning the system cable S30267-Z167-Axxx
Power supply unit
The DIUT2 board receives +5 V (±5%) supply voltage via the backplane. Voltage of +1.5 V and
+3.3 V is created by onboard controllers.
TMS X7-46 Boundary scan: check mode
selection
Not connected
TDI X7-48 Boundary scan: Check data
input
Not connected
TDO X7-50 Boundary scan: Check data
output
Not connected
Table 3-37 DIUT2 - Assignment of System Cable S30267-Z167-Axxx
Pin Function Color code
8 a-wire (T), transmit ora/wht
15 b-wire (R), transmit wht/ora
1 a-wire (T), receive blu/wht
9 b-wire (R), receive wht/blu
Signal Name Connector contact Signal description Direction
Table 3-36 SIPAC Connector Contact Assignment
