Boards for HiPath 3000 Nur für den internen Gebrauch

A31003-H3590-S100-7-7620, 06/2012

3-102 HiPath 3000/5000 V9, Service documentation

boards.fm

Peripheral boards

Front panel

An additional shielding panel is not required on the front side of this board, because the EMC

shield is already provided by the front panel.

Figure 3-37 IVMNL, IVMN8 - Front Panel (S30122-H7688-X -X100)

Lockout switch

Two LEDs indicating the board status:

● LED (green)

● LED (yellow)

Ethernet (10/100BaseT) interface (8-pin RJ45 jack)
