boards.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
3-103
Nur für den internen Gebrauch Boards for HiPath 3000
Peripheral boards
Lockout switch settings
● Pressed = free (default)
● Not pressed = locked: existing connections remain active, new connections are locked.
– The yellow LED lights up when all connections are ended and the board is effectively
locked.
– The yellow LED flashes when a lockout request is entered (via lockout switch or soft-
ware) but at least one call is still active.
To reset the board to the default state, press the lockout switch four times (off-on-off-on) during
the LED test at startup. This action cancels the LED test and both LEDs flash for approximately
five seconds in confirmation.
LED statuses and their meanings
Table 3-42 IVMNL, IVMN8 - LED Statuses
LED
yellow
LED
green
Meaning Action
During Startup and Initialization
Off Off 1 Boot procedure (lasts approx. 60
s)
On On 2 LED test (lasts approx. 10 s)
On Off 3 Lockout switch state signaling by
yellow LED (lasts approx. 5 s):
● blocked = On
● free = Off
Possibly check if board was de-
activated using HiPath 3000/
5000 Manager E or lockout
switch.
Off
Flashing
(500/
500 ms)
Off 4 Hard disk test, application startup
(depending on hard disk status,
lasts approx. 2 - 9 minutes)
Off On 5a Standby mode after successful
boot
On Off 5b Board locked or board error oc-
curred
Check whether board was deac-
tivated using HiPath 3000/5000
Manager E or lockout switch.
Change board if faulty.
During Operation
Off On Idle (no call)
