Peripheral boards
RJ45 jack assignment
Flashing
(500/
500 ms)
Off At least one active port (call)
Flashing
(500/
500 ms)
Flashing
(500/
500 ms)
Lockout switch activated during a call
On Off Board locked or board error occurred Check whether board was deac-
tivated using HiPath 3000/5000
Manager E or lockout switch.
Change board if faulty.
Flashing
(100/
100 ms)
Off Upgrade process active
Table 3-43 IVMNL, IVMN8 - RJ45 Jack Assignment
Pin Signal Description
1 Tx + Transmit +
2 Tx – Transmit –
3Rx+Receive+
4 – Not used
5 – Not used
6Rx–Receive–
7 – Not used
8 – Not used
Table 3-42 IVMNL, IVMN8 - LED Statuses
LED
yellow
LED
green
Meaning Action
