Peripheral boards
System configuration using SLC16N
For information on the maximum possible system configuration of HiPath Cordless Office with
SLC16N boards, see Table 11-1.
Supplying power to base stations
Power is supplied to the base stations primarily via the internal PSU in the system in question.
● HiPath 3550
Subject to certain prerequisites, the system-internal PSU UPSC-D provides sufficient pow-
er for the operation of sixteen BS3/1s (one U
P0/E
each) or eight BS3/3 (two U
P0/E
each).
These prerequisites depend on the
– Line length and line type between SLC16N and base station.
The following specifications are based on line lengths of up to 1000 m and a line type
2x0.6 mm per U
P0/E
.
– Number and type of corded telephones connected to the system.
Table 3-62 through Table 3-63 show which telephone configurations work without ad-
ditional power supply.
Table 3-62 HiPath 3550 - Maximum Number of Corded Telephones Depending on the
Number of BS3/1 Base Stations Connected to SLC16N and BS4s con-
nected to SLC16N (not for U.S.)
Number
of BS3/1s and BS4s
connected via 1xU
P0/E
to
SLC16N
Maximum number of corded telephones
Analog telephones
0 1-10 11-20 21-30 31-40 41-50
optiPoint 500 (digital telephones)
1 666157534844
2 635954504641
3 605652474339
4 585349454036
5 555147423833
6 534844403531
7 504641373328
8 474339343026
9 454036322723
10 42 38 33 29 25 20
11 40 35 31 27 22 18
12 37 33 28 24 20 15
13 34 30 26 21 17 13
