Table 3-90 SLMAV8, SLMAV24 - Connector Panel Assignment with SIPAC 1 SU Connec-
tors (Cable for ports 1 - 16)
Color
Group
Pair
a-wire
(tip)
1
1 see “Abbreviations for colors“ at the start of Section 3.3.
b-wire
(ring)1
SU con-
nector
SLMAV8,
SLMAV24
MDFU-E
Patch Panel,
MW8 pin
Notes
1
1
wht/blu 19 1a
Port 1
1a 4
blu/wht 39 1b 1b 5
2
wht/ora 38 2a
Port 2
2a 4
ora/wht 48 2b 2b 5
3
wht/grn 27 3a
Port 3
3a 4
grn/wht 47 3b 3b 5
4
wht/brn 16 4a
Port 4
4a 4
brn/wht 46 4b 4b 5
5
wht/gry 05 5a
Port 5
5a 4
gry/wht 45 5b 5b 5
2
6
red/blu 14 6a
Port 6
6a 4
blu/red 44 6b 6b 5
7
red/ora 23 7a
Port 7
7a 4
ora/red 43 7b 7b 5
8
red/grn 32 8a
Port 8
8a 4
grn/red 42 8b 8b 5
9
red/brn 11 9a
Port 9
9a 4
not used
in
SLMAV8
brn/red 31 9b 9b 5
10
red/gry 02 10a
Port 10
10a 4
gry/red 22 10b 10b 5
3
11
blk/blu 13 11a
Port 11
11a 4
blu/blk 33 11b 11b 5
12
blk/ora 04 12a
Port 12
12a 4
ora/blk 24 12b 12b 5
13
blk/grn 15 13a
Port 13
13a 4
grn/blk 35 13b 13b 5
14
blk/brn 06 14a
Port 14
14a 4
brn/blk 26 14b 14b 5
15
blk/gry 17 15a
Port 15
15a 4
gry/blk 37 15b 15b 5
416
yel/blu 08 16a
Port 16
16a 4
blu/yel 28 16b 16b 5
