Table 3-91 SLMAV8, SLMAV24 - Connector Panel Assignment with SIPAC 1 SU Connec-
tors (Cable for ports 17 - 24)
Color
Group
Pair
a-wire
(tip)
1
1 see “Abbreviations for colors“ at the start of Section 3.3.
b-wire
(ring)1
SU con-
nector
SLMAV8,
SLMAV24
MDFU-E
Patch Panel,
MW8 pin
Notes
1
1
wht/blu
Free
blu/wht
2
wht/ora
Free
ora/wht
3
wht/grn
Free
grn/wht
4
wht/brn
Free
brn/wht
5
wht/gry
Free
gry/wht
2
6
red/blu
Free
blu/red
7
red/ora
Free
ora/red
8
red/grn
Free
grn/red
9
red/brn 11 17a
Port 17
17a 4
not used
in
SLMAV8
brn/red 31 17b 17b 5
10
red/gry 02 18a
Port 18
18a 4
gry/red 22 18b 18b 5
3
11
blk/blu 13 19a
Port 19
19a 4
blu/blk 33 19b 19b 5
12
blk/ora 04 20a
Port 20
20a 4
ora/blk 24 20b 20b 5
13
blk/grn 15 21a
Port 21
21a 4
grn/blk 35 21b 21b 5
14
blk/brn 06 22a
Port 22
22a 4
brn/blk 26 22b 22b 5
15
blk/gry 17 23a
Port 23
23a 4
gry/blk 37 23b 23b 5
416
yel/blu 08 24a
Port 24
24a 4
blu/yel 28 24b 24b 5
