boards.fm
A31003-H3590-S100-7-7620, 06/2012
HiPath 3000/5000 V9, Service documentation
3-229
Nur für den internen Gebrauch Boards for HiPath 3000
Peripheral boards
S
0
interface assignment
Figure 3-72 STLSX2, STLSX4, STLSX4R - Interfaces
Table 3-106 STLSX2, STLSX4, STLSX4R - S
0
Interface Assignment
X2
Pin
S
0
port 1 X2
Pin
S
0
port 2 X2
Pin
S
0
port 3
1
1 Not for STLSX2
X2
Pin
S
0
port 4
1
11–21–31–41–
12–22–32–42–
13 Transmit + 23 Transmit + 33 Transmit + 43 Transmit +
14 Receive + 24 Receive + 34 Receive + 44 Receive +
15 Receive – 25 Receive – 35 Receive – 45 Receive –
16 Transmit – 26 Transmit – 36 Transmit – 46 Transmit –
17–27–37–47–
18–28–38–48–
CUP/CUC
(for STLSX2/
STLSX4)
CUPR/CUCR
(for STLSX4R)
X2
X1
50
2
4 S
0
ports
(MW8 (RJ45)-
jacks)
11
48
S
0
port 1
S
0
port 4
8 ... 1
MW8 (RJ45) jack assignment:
3 = Transmit +
4 = Receive +
5 = Receive –
6 = Transmit –
S
0
ports 3 and 4 are
not assigned in
STLSX2.
