3-245

Nur für den internen Gebrauch Boards for HiPath 3000

Peripheral boards

Interfaces and Jumpers

Figure 3-78 TCAS-2 (S30810-Q2945-X) (for selected countries only) – Figure

Figure 3-79 TCAS-2, TCASR-2 (for selected countries only) – Interfaces and Jumpers

X13

X21

X12

3 2 1

X14

X20

Modem (optional)

X805: Analog modem

X910

X909

X803: V.24 interface

X804: Ethernet (10/

100BaseT) interface

X11

X16

3 2 1

X17

CAS interface 1:

X911

X912

CAS interface 2:

3 2 1
