Peripheral boards
Settings
Table 3-115 TCAS-2, TCASR-2 (for selected countries only) – Jumper Functions
Jumper Function Setting
Pins 1–2 closed Pins 2–3 closed
X11 Sets the V.24 baud rate See Table 3-116
X12
X14
X13 Deletes the flash mem-
ory
Flash memory is deleted
(all sectors apart from U-
boot (firmware)).
Flash memory is not de-
leted.
(default setting)
X16 Resetting the card Reset performed. Reset not performed.
(default setting)
X17 Hardware watchdog Watchdog active.
(default setting)
Watchdog not active.
Table 3-116 TCAS-2, TCASR-2 (for selected countries only) – Jumper for Setting the V.24
Baud Rate
V.24 baud rate
(Kbps)
Jumper
X11 X12 X14
9.6
(default setting)
Open Open Open
19.2 Open Open Closed
38.4 Closed Open Closed
57.6 Open Closed Closed
115.2 Closed Closed Closed
9.6 All other configurations
