boards.fm

A31003-H3590-S100-7-7620, 06/2012

HiPath 3000/5000 V9, Service documentation

3-279

Nur für den internen Gebrauch Boards for HiPath 3000

Peripheral boards

Jumper for setting the procedure for analog trunk interfaces

Process settings for the analog trunk interface is via X105 and X106 jumpers.

● Loop start setting = pins 1–2 closed (default)

● Ground start setting = Pins 2 - 3 closed

MW8 jack X5, pin ALUM 1 + 2

5 54 b ALUM1: Subsc. line module connection

55 a

6 64 b ALUM2: Subsc. line module connection

65 a

7 74 b ALUM1: Analog telephone connection

75 a

8 84 b ALUM2: Analog telephone connection

85 a

Table 3-133 TLANI4R - Contact Assignments
