Peripheral boards
Seven-segment display
The card’s software status can be ascertained on the basis of the seven-segment display. For
this a distinction is made between the following boot phases:
● U-boot (firmware) states
Table 3-148 TMCAS-2 (for selected countries only) – U-boot (firmware) States
Display Meaning
Initializing hardware
Downloading DSP (Digital Signal Processor) firmware
Downloading FPGA (Field Programmable Gate Array) firmware
Accessing flash EPROM (Save and Delete)
Activating built-in self test BIST (BIST1 or BIST2)
Administration (Service PC connected)
Copying software (from SDRAM to FEPROM)
U-boot
(Firmware)
Power supply unit switched on
Linux operating system
Initializing
U-boot
(Firmware)
CAS application software
The decimal point is flashing to indicate that the U-
boot firmware is operational.
The decimal point is activated (not flashing) to indi-
cate initialization of the Linux operating system.
The decimal point is activated when the card sup-
plies the clock reference for the system.
