Nur für den internen Gebrauch Installing HiPath 3000
Installing HiPath 3800
Information on cable and connector assignment is provided in the board descriptions in Chap-
ter 3.
Slot with
SLMA
SLMA2
1
SLMO2
CABLUs for connection between backplane (SIVAPAC connector) and
MDFU-E (jumper strip for 25 TW):
● C39195-A7267-A372: 3 m in length, short stripped length for MDFU-E
slots 11-21 (see Figure 4-36)
● C39195-A7267-A373: 3 m in length, long stripped length for MDFU-E
slots 1-10 (see Figure 4-36)
CABLU for connection between backplane (SIVAPAC connectors) and ex-
ternal patch panel S30807-K6143-X (SIVAPAC socket terminal strip):
● S30267-Z333-A20: 2m in length (refer to Figure 4-42)
● S30267-Z333-A50: 5 m in length (refer to Figure 4-42)
Open-end cable (24 TW) for connection between backplane (SIVAPAC
connector) and external patch panel:
● S30267-Z196-A150: 15 m in length
● S30267-Z196-A250: 25 m in length
● S30267-Z196-A350: 35 m in length
● S30267-Z196-A550: 55 m in length
● S30267-Z196-A950: 95 m in length
1 for selected countries only
2 For U.S. only
