System Data Nur für den internen Gebrauch
A31003-H3590-S100-7-7620, 06/2012
2-28 HiPath 3000/5000 V9, Service documentation
sysdat.fm
HiPath 3000
Trunk Boards
Table 2-11 Trunk Boards for HiPath 3550
Board
Name
Capacity Coun-
try
Type/Description
Ports per board
B channels per board
Max. number of
boards per system
ROW
USA
TCAS-2 2 60
1
1 TCAS-2 provides two E1 CAS interfaces which, combined, can support up to 60 B channels. As HiPath 3550 supports a
maximum of 30 B channels, a total of up to 30 B channels may be used.
1x
2
2 For selected countries only
- Board for supporting country-specific
CAS (Channel Associated Signaling) protocols
TLA 2 #
3
x - Trunk board for analog lines
TLA4 4 #
3
x - Trunk board for analog lines
TLANI2 2 #
3
x x Trunk board for analog lines including ALUM
TLANI4 4 #
3
x x Trunk board for analog lines including ALUM
TLANI8 8 #
3
x x Trunk board for analog lines including ALUM
TLA8 8 #
3
x - Trunk board for analog lines
TS2N 30 30 1 x - Board for primary rate access; can be used for tie trunk traf-
fic.
In HiPath 3000/5000 V5.0 and later, the B channels in the
TS2N board are subject to license. Consequently, the
TS2N boards (S30810-Q2913-X300) have been assigned
a new hardware identification code. The new code prevents
the board from being used in earlier versions. Functionality
and layout of the board have not been changed.
STLS2 2 4 #
3
x - Board for ISDN basic rate access.
Configuration of ISDN trunks, tie trunks, and stations (no
feeding) on the same board is possible.
STLS4 4 8 #
3
xx
TST1 1 24 1 - x PRI board
TMGL4 4 #
3
- x Trunk board for analog lines
TMQ4 4 8 #
3
- x BRI board
