Siemens SIMADYN D Hardware Manual

Plug-in cables
9-6 Hardware - SIMADYN D
Edition 06.2002
Ribbon cable
SC17.2
50 pin
Application
Connects the SITOR interface of an expansion module
with the SITOR interface of a SITOR thyristor set or an
SE20.2 interface module.
Features
• screened round cable
• twisted pairs
• 50-pin SUB-D plug connector
• 50-pin SUB-D socket connector
• (1:1) connection
Cable ends
SUB-D plug connectors according to DIN 41652 are
provided at both ends
Length 2 m
Order No. 6DD1684-0BH2
Table 9-6 Ribbon cable SC17.2
Ribbon cable
SC31.2
50 pin
Application
Connects the SITOR interface of an expansion module
with the SITOR interface of a SITOR thyristor set or an
SE20.2 interface module.
Features
• screened round cable
• twisted pairs
• 50-pin SUB-D plug connector
• 50 pin SUB-D socket connector
• (1:1) connection
Cable ends
SUB-D plug connectors according to DIN 41652 are
provided at both ends
Length 10 m
Order No. 6DD1684-0DB2
Table 9-7 Ribbon cable SC31.2
SC17.2
SC31.2
