Siemens SIMADYN D Hardware Manual

Plug-in cables
Hardware - SIMADYN D 9-11
Edition 06.2002
9
Sub-D connector Plug connector Sub-D connector Socket connector
Partial connect. A Partial connector D
1 1 11 1
34 2 44 2
18 3 28 3
2 4 12 4
35 5 45 5
19 6 29 6
3 7 13 7
36 8 46 8
20 9 30 9
4 10 14 10
Partial connect. B Partial connector E
37 1 47 1
21 2 31 2
5 3 15 3
38 4 48 4
22 5 32 5
6 6 16 6
39 7 49 7
23 8 33 8
7 9 17 9
40 10 50 10
Partial connect. C
24 1
8 2
41 3
25 4
9 5
42 6
26 7
10 8
43 9
27 10
Table 9-12 Ribbon cable SC54
