Siemens SINAMICS Series Equipment Manual

Cabinet Configuration and EMC Booksize
7.4 Arrangement of components and devices
Equipment Manuel for Booksize Power Modules
7-18 Manual, (GH2), Edition 06.2005, 6SL3097-2AC00-0BP2
For modules with a width of between 150 and 300 mm, the distance between the upper and
lower module row must be at least 500 mm.
Caution
Signal cables must not be routed parallel to power cables.
Wiring rules for DRIVE-CLiQ
See the Commissioning Manual.
Overview of the DC link supply adapter and DC link adapter
Suitable for module width: Max. connectable cross-
section
Max. current carrying capacity
DC link supply adapter (cable outlet on top)
6SL3162-2BD00-0AAx 50 mm, 100 mm 10 mm
2
36 A
6SL3162-2BM00-0AAx 150 mm, 200 mm, 300 mm 95 mm
2
240 A
DC link adapter (cable outlet on side)
6SL3162-2BM01-0AAx all 95 mm
2
240 A
Note
The current carrying capacity of the DC link busbars must be taken into account. For the
specifications, see the technical specifications for the module.

Siemens SINAMICS Series Specifications

General

Product Line	SINAMICS
Cooling Method	Air-cooled, Liquid-cooled
Voltage Range	200 V to 690 V
Power Range	0.12kW - 250kW
Communication Interfaces	PROFINET, PROFIBUS, Ethernet
Control Modes	Vector control, V/f control
Protection Class	IP20
Type	Variable Frequency Drives (VFD)
