Appendix
A.4 Parameterization using the BOP20
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
1055
Parameter filter Using the parameter filter in p0004, the available parameters can be filtered corresponding to
their particular function.
Selecting the operating
display
Actual values and setpoints are displayed on the operating display.
The operating display can be set using p0006.
Using the user parameter list in p0013, parameters can be selected for access.
Unplug while voltage is
present
The BOP can be withdrawn and inserted under voltage.
• The ON key and OFF key have a function.
When withdrawing, the drives are stopped.
After inserting, the drives must be switched on again.
• The ON key and OFF key have no function.
Withdrawing and inserting has no effect on the drives.
Actuating keys The following applies to the "P" and "FN" keys:
• When used in a combination with another key, "P" or "FN" must be pressed first and then
the other key.
Overview of important parameters (see SINAMICS S120/S150 List Manual)
p0005[0...1]
BOP status display selection
p0006
p0013[0...49]
-defined list
p0971
Save drive object parameters
Drive object, Control Unit
r0002
Control Unit status display
p0003
p0004
OP display filter
p0007
p0008
BOP drive object after powering up
p0009
Device commissioning parameter filter
p0011
BOP password input (p0013)
p0012
BOP password confirmation (p0013)
r0019.0...14
p0977
ll parameters
Other drive objects (e.g. SERVO, VECTOR, X_INF, TM41 etc.)
p0010
Drive, commissioning parameter filter
