Communication
11.1 Communication according to PROFIdrive
Drive functions
770 Function Manual, 11/2017, 6SL3097-4AB00-0BP5
The other diagnostics data (types) can be in any sequence. This is the reason that the
following diagnostics data include a header:
● Identifier-related diagnostics
● Status messages/module status
● Channel-related diagnostics
The diagnostic data type can be uniquely identified based on the header.
Note
The master must operate in the DPV1 mode.
Standard diagnostics
For communication via PROFIBUS, standard diagnostics is structured as follows.
Bit
7
6
5
4
3
2
1
0
Octet
Name
1 Station
status 1
Master_
Lock
= 0
Prm_Fault 0 Not_
Supported
Ext_Diag
Cfg_Fault Station_
Not_
Ready
Station_
Non_
Exist
= 0
2 Station
status 2
0 0 Sync_
Mode
Freeze_
Mode
WD_On 1
Stat_Diag
= 0
Prm_Req
3 Station
status 3
Ext_
Diag_
Overflow
0 0 0 0 0 0 0
4
Master_Add
5
Ident_Number (HighByte) of the slave
6
Ident_Number (LowByte) of the slave
In this context, the following values are decisive for diagnostics:
● Ext_Diag
– Group signal for diagnostics in the slave
– = 1, if at least 1 alarm is active
● Ext_Diag_Overflow
Display, diagnostics overflow in the slave (for more than 240 bytes)
