4.4 Speed controller
Drive functions
Function Manual, 11/2017, 6SL3097-4AB00-0BP5
97
● OFF3
– Switch to speed-controlled operation
– n_set = 0 is input immediately to brake the drive along the OFF3 deceleration ramp
(p1135).
– When standstill is detected, the motor brake (if parameterized) is closed.
– The pulses are suppressed when the motor brake application time (p1217) has
elapsed. Standstill is detected when the actual speed value is less than the speed
threshold (p1226) or when the monitoring time (p1227) that started when speed
setpoint ≤ speed threshold (p1226) has expired.
– Switching-on inhibited is activated.
Parameterization with STARTER
The "Torque setpoint" parameter screen is selected with the icon in the toolbar of the
STARTER commissioning tool.
Function diagrams (see SINAMICS S120/S150 List Manual)
•
5060
Servo control - Torque setpoint, switchover control mode
•
5610
Servo control – torque limiting/reduction, interpolator
Overview of important parameters (see SINAMICS S120/S150 List Manual)
•
p1300[0...n]
Open
-loop/closed-loop control operating mode
•
r1406.8...12
CO/BO: Control word, speed controller
•
p1501[0...n]
BI: Change over between closed
-loop speed/torque control
•
p1511[0...n]
CI: Supplementary torque 1
•
p1512[0...n]
CI: Supplementary torque 1 sc
aling
•
p1513[0...n]
CI: Supplementary torque 2
•
r1515
Supplementary torque total
