Simrad EK80 Installation Manual

394149/C
103
MoxaCP114EL-ISeriallineadapter
TheMoxaCP114EL-IserialadapterboardisusedintheEK80ProcessorUnittoprovide
serialcommunication.
Topics
MoxaCP114EL-Ioverview,page103
MoxaCP114EL-Iconnectors,page104
MoxaCP114EL-Ioverview,page103
MoxaCP114EL-Iconnectors,page104
MoxaCP114EL-Ioverview
TheProcessorUnitisequippedwithaMoxaCP114EL-Iserialadapterboard.Theboard
providesfourseriallines.
TheMoxaCP114EL-IserialadaptersupportsRS-232,
RS-422andRS-485(both2and4-wire).
Theconnectionstotheboardaremadeusingaconverter
cablewithfour9-pinmaleD-connectors.Theconverter
cableissuppliedwiththeProcessorUnit.
•Manufacturer:Moxa
•Manufacturer’swebsite:http://www.moxa.com
Seriallinesupport
TheMoxaCP114EL-Iserialadaptersupportsthefollowinginterfaceformats:
•Port1:RS-232/RS-422/RS-485
•Port2:RS-232/RS-422/RS-485
•Port3:RS-232/RS-422/RS-485
•Port4:RS-232/RS-422/RS-485
Adedicatedsoftwareutilityinthedevicedriverisusedtosetuptheportstomatchyour
requirements.Forthisreason,thereareneitherjumpersnorDIPswitchesonthecircuit
board.
Relatedtopics
Topsidecableplan,page79
Cablelayoutandinterconnections
