Simrad EK80 Installation Manual

90
394149/C
4Ifspeciedintherelevantinstallationmanual,connectthegroundingcablefromthe
nearestgroundingpointtotherelevantcontactpointorsocketontherearsideofthe
display.
5Ifrelevant,connectthegroundingcabletovesselgroundinthefusebox(orother
commongroundingpoint).
Relatedtopics
ACmainspowercableusingIECC13inlinesocket,page107
ConnectingthevideocablefromtheProcessorUnittothe
display
Thevideointerfacecableisastandardcommercialcable.Severalvideostandardsexist.The
cableisnormallyprovidedwiththedisplay.
Prerequisites
Youmustbeequippedwithastandard
setoftools.Thistoolsetmustcomprise
thenormaltoolsforcableinstallation,
suchasdifferentscrewdrivertypes,
pliers,acablestripperandasoldering
iron.Eachtoolmustbeprovidedin
varioussizes.Werecommendthatall
toolsaredemagnetizedtoprotectyour
equipment.Dependingonthetasksat
hand,additionaltoolsmayberequired.
Context
Thedisplaycableisoftenphysically
attachedtothedisplay,andterminatedinthe“computerend”withamaleconnector.
Ifthe
cableisnotattached,itisnormallyprovidedwiththedisplay.
ThegraphicadapterontherearsideoftheProcessorUnitprovidestwoDVIconnectors,one
forHDMIandtwoforDisplayPort.Choosetheconnectorthattsyourdisplaycable.Ifyou
havetwodisplaysbothcanbeconnectedsimultaneously,andcanusetheoperatingsystem
functionalitytosetupdifferentpresentations.
Keepthedisplaycableasshortaspossible.Ifthecableistoolong,itmaypickupelectric
noise,andthiswillreducetheimagequality.
