Simrad EK80 - Split Beam Transducer to Single Beam Output on GPT Transducer Socket

394149/C
121
Note
Theblackwiresinthetransducercablearenotforgrounding.Youmustneverconnectthese
together,andyoumustnotconnectanyofthemtovesselground.
Ifyouneedtosplicethetransducercable,westronglyrecommendtheuseofametal
junctionboxwithpropercableglands.Thecablescreenmustbeconnectedtothecable
glands.Thecablescreenandthejunctionboxchassismustnotbeconnectedtovessel
ground.Avoidgroundloops.Youmustusethesametypeofcableastheoriginaltransducer
cable,contactKongsbergMaritimeforadvice.
Westronglyrecommendthatyouinstallthetransducercableinasteelconduit.
Minimumcablerequirements
Notapplicable.Ifyouneedanextensioncable,contactyourdealer(orKongsbergMaritime)
forsupport.
SplitbeamtransducertosinglebeamoutputonGPT
Transducersocket
AsplitbeamtransducercanbeconnectedtosocketsCandDonaGPTtypetransducer
socket.Thisallowsyoutousethetransducerasasinglebeamunit.
Theotherendofthecableispermanentlyxedtothetransducer.
M
E
F
J
H
D
C
K
L
A
B
N
FOR WARD
3
4
2
1
H
L
D
A
E
B
F
C
J
M
N
(CD0808_001_004)
A
1
2
4
3
Cablelayoutandinterconnections
