Simrad EK80 Installation Manual

72
394149/C
6Placecabinetinitscorrectpositiononthebottomframe.
aUsefourboltsthroughthebottomframetosecurethecabinet.
bMountthetopshockabsorberstothebulkheadsupportbracket(s).
7Fastentheearthstrap.
Relatedtopics
400930WBTCabinetoutlinedimensions,page210
Equipmenthandling,page227
Compasssafedistance,page223
MountingthedrawersintheWBTCabinet
TheWBTCabinetcancontainmaximumsevencustomdrawers.Eachdrawerwillholdone
WideBandTransceiver(WBT)anditspowersupply.Thedrawerismountedinthesame
wayasanyotherequipmentdesignedfor19"racksusingstandardtools.
Prerequisites
Youmustbeequippedwithastandardsetoftools.Thistoolsetmustcomprisethenormal
toolsforelectronicandelectromechanicaltasks,suchasscrewdrivers,pliers,spanners,a
cablestripperetc.Eachtoolmustbeprovidedinvarioussizes.Werecommendthatalltools
aredemagnetizedtoprotectyourequipment.
Context
WerecommendthatyoumountalltheemptydrawersintotheWBTCabinetbeforeyou
mounttheWideBandTransceiver(WBT)unitoneachdrawer.
