Simrad12-16/60connectiontoacirculartransducersocket
TheSimrad12–16/60dualbeamtransducercanbeconnectedtosocketsC,DandNona
circular12-pinAmphenoltransducersocket.ThissocketisusedontheGeneralPurpose
Transceiver(GPT),andonsomeversionsoftheWideBandTransceiver(WBT).
M
E
F
J
H
D
C
K
L
A
B
N
C
C
D
D
N
N
(CD0808_001_021)
Beam
CablecoloursTerminalon
socket
Brown
C
Blue
—
Yellow
D
Wide
Black
—
Brown
Blue
C
Yellow
Narrow
Black
D
AUsethiswiringforwidebeam
BUsethiswiringfornarrow
beam
CConnectorsonthe12-pin
Amphenoltransducersocket
(notethatonlyC,DandNare
used)
D12-pinAmphenoltransducer
socketseenfromoutside
Cablescreen
Screen
N
ThecablescreenmustbeconnectedtothehousingonthetransducerplugandtoterminalN.
Ifyouneedtosplicethetransducercable,westronglyrecommendtheuseofametal
junctionboxwithpropercableglands.Thecablescreenmustbeconnectedtothecable
glands.Thecablescreenandthejunctionboxchassismustnot
beconnectedtovessel
ground.Avoidgroundloops.Youmustusethesametypeofcableastheoriginaltransducer
cable,contactKongsbergMaritimeforadvice.
Westronglyrecommendthatyouinstallthetransducercableinasteelconduit.
Cablelayoutandinterconnections
