Simrad EK80 - Simrad 50;200 Combi C Connection to a Circular Transducer Socket

394149/C
129
Note
Theblackwiresinthetransducercablearenotforgrounding.Youmustneverconnectthese
together,andyoumustnotconnectanyofthemtovesselground.
Ifyouneedtosplicethetransducercable,westronglyrecommendtheuseofametal
junctionboxwithpropercableglands.Thecablescreenmustbeconnectedtothecable
glands.Thecablescreenandthejunctionboxchassismustnotbeconnectedtovessel
ground.Avoidgroundloops.Youmustusethesametypeofcableastheoriginaltransducer
cable,contactKongsbergMaritimeforadvice.
Westronglyrecommendthatyouinstallthetransducercableinasteelconduit.
Minimumcablerequirements
Notapplicable.Ifyouneedanextensioncable,contactyourdealer(orKongsbergMaritime)
forsupport.
Simrad50/200CombiCconnectiontoacirculartransducer
socket
TheSimrad50/200CombiCtransducercanbeconnectedtosocketsC,D,HandJona
circular12-pinAmphenoltransducersocket.
ThissocketisusedontheGeneralPurpose
Transceiver(GPT),andonsomeversionsoftheWideBandTransceiver(WBT).
Theotherendofthecableispermanentlyxedtothetransducer.
M
E
F
J
H
D
C
K
L
A
B
N
3
1
6
5
4
2
7
3
1
6
5
4
2
7
H
D
A
E
B
F
C
J
(CD0808_001_022)
ATransducer-Thecableisttedwitha7–pinMini-Con-Xfemaleplug
Cablelayoutandinterconnections
