Simrad EK80 Installation Manual

394149/C
155
PoweringuptheEK80forthersttime
Topics
Settingupsummary,page155
InstallingtheEK80operationalsoftware,page157
PoweringuptheEK80toPassivemode,page158
Obtainingandinstallingthesoftwarelicense,page159
DeningtheIPaddressontheProcessorUnitnetworkadapterforcommunicationwiththe
WideBandTransceiver(WBT).,page161
Installingoneormoretransducers,page162
Installingtransceiverchannels,page164
Adjustingthescreenresolution,page166
Settingupsummary
BeforeanewEK80Widebandscienticechosoundercanbeputtouse,itmustbesetup
foroperation.Youmustinstallthesoftware,andconguretransducer(s)andtransceiver(s).
Prerequisites
•TheEK80Widebandscienticechosoundersystemunitshaveallbeeinstalled
accordingtotheinstructionsprovided.
•Allpowerandinterfacecablesandconnectionshavebeenconnectedandveried.
•Allsystemunitshavebeeninspected.
•TheEK80operationalsoftwareisavailable.
•TheEK80softwarelicenseisavailable.
Caution
YoumustneverpoweruptheEK80whentheshipisindrydockThetransducerwillbe
damagedifittransmitsinopenair.
Procedure
1Dothefollowingpreparations:
Settingtowork
