394149/C
63
5Ifyouinstallthepowersupplyusingthebrackets:
aPlacethepowersupplyinasuitablelocation(verticalorhorizontal).
bSecurethepowersupplyusingthebrackets,aswellastheboltsorscrewsincluded.
6Ifyoupreferanad-hocinstallation:
aPlacethepowersupplyinasuitablelocation(verticalorhorizontal).
bSecurethepowersupplyusinganymeansavailable.
7Connectthecables.
Note
Whenyouconnectthecables,makesurethattheyareallproperlysecured,andable
towithstandthevibrationandmovementsofthevessel.
Relatedtopics
Equipmenthandling,page227
Compasssafedistance,page223
Installingthedisplay
ThedisplayisnormallynotincludedwiththeEK80delivery.Agenericprocedureis
thereforeprovided.
Weassumethatyouareequippedwithastandardsetoftools.Thistoolsetmustcomprise
thenormaltoolsforelectronicandelectromechanicaltasks,suchasscrewdrivers,pliers,
spanners,acablestripperetc.Eachtoolmustbeprovidedinvarioussizes.Werecommend
thatalltoolsaredemagnetizedtoprotectyourequipment.
Asuitablelocationforthedisplaymustbedenedpriortoinstallation.
Note
Observethecompasssafedistance.
Procedure
1Preparethelocationandthenecessarytools.
InstallingtheEK80hardwareunits
