Simrad EK80 Installation Manual

394149/C
225
•Operatingsystem:TheEK80softwarehasbeendesignedfor64-bitWindows®7.Itwill
alsoworkon32-bitsystems.Olderoperatingsystemsarenotsupported.
Alargenumberofcommercialgraphicadaptersareavailable,andwehavenottestedallof
them.EvenadaptersthatmeettheminimumspecicationsmayfailwiththeEK80software.
Wewelcomeanyfeedbackwithcommentsorexperienceswithgraphicadapters.
Tip
IfyouhaveconnectedaUSB-to-serialadaptertotheProcessorUnit,donotremoveit
whiletheEK80isrunning.Also,donotmovetheadaptertoadifferentUSBsocketon
theProcessorUnit.
Relatedtopics
ProcessorUnitdescription,page19
Additionalrequireditems,page28
Minimumtechnicalrequirementsfordisplay
Unlessspecicallyordered,theEK80isnotprovidedwithadisplay.Thisitemmustthen
bepurchasedlocally.
YoucanuseoneortwodisplaysonyourEK80ProcessorUnitdependingonpersonaland
operationalpreferences.
Note
Itisimportantthatthechosendisplaymeetsthetechnicalsystemrequirements.The
displaydesignandconstructionmustallowformaritimeuse,easyaccesstocables,and
asafeinstallation.
Theminimumtechnicalrequirementsare:
•Resolution:
–Minimum:1280x1024pixels.
–Recommended:1920x1200pixelsorbetter
•Videointerface:ThesemustmatchthevideooutputformatsprovidedbytheProcessor
Unit.
TheProcessorUnitoffersvideooutputonseveralformats.Investigateyouroptions
beforepurchasingadisplay.
Technicalspecications
