Simrad EK80 Installation Manual

42
394149/C
3InstalltheEK80systemunits.
NotethatsomeEK80systemunitsmaybecommercial.Unlessorderedspecically
thesearenotincludedinthedelivery,andmustbepurchasedlocally.
4InstallthecablesbetweentheEK80systemunits.
Observetherelevantcableplan,procedures,aswellasthegeneralrequirementsfor
cabling.
5PoweruptheEK80forthersttime,andsetittowork.
Note
InordertosetuptheEK80inasafeandcorrectmanner,theseproceduresmustbe
compliedto!
6Connecttheperipheralunits.
7Runacompletesystemtest.
ThetestsaredescribedinSettingtoworkchapterinthismanual,aswellasinthe
HarbourAcceptanceTestandtheSeaAcceptanceTestdocuments.
Furtherrequirements
FillinandsigntheInstallationRemarksform,andsendittoSimrad'ssupportdepartment
asspeciedontheform.
Aboutinstallationdrawings
Theinstallationshipyardmustprovideallnecessarydesignandinstallationdrawings,as
wellastherelevantworkstandardsandmountingprocedures.
Note
Ifrequired,alldocumentsprovidedbytheshipyardforthephysicalinstallationoftheEK80
mustbeapprovedbythevessel’ snationalregistryandcorrespondingmaritimeauthority
and/orclassicationsociety.Suchapprovalmustbeobtainedbeforetheinstallationcan
begin.Theshipownerandshipyarddoingtheinstallationareresponsibleforobtainingand
payingforsuchapproval.
KongsbergMaritimeoffersfreeadviceforinstallationplanning.Proposedarrangements
maybesentforcommentaryorsuggestions.Thefollowingdrawingsshouldbesubmitted
shouldassistanceberequested:
SimradEK80
