Simrad EK80 Installation Manual

118
394149/C
Batterypowercable
AsuitablecablemustbeprovidedifyouwishtopowertheWideBandTransceiver(WBT)
fromabattery.
1
4
3
2
Thepowersocketismountedontherearpanelof
theWideBandTransceiver(WBT).
ThesocketismadetotaConxall4-pin
Mini-Con-X
®
shieldedplug.Onespareplugis
includedwiththeEK80delivery,youcanusethis
ifyouwishtopowertheWideBandTransceiver
(WBT)fromabattery.
Theplugcanalsobeorderedfromthemanufacturer(http://www.conxall.com),orpurchased
fromKongsbergMaritimeusingordernumber390616.
Pinconguration
Pin1234
Use
+12Vdc0Vdc0Vdc+12Vdc
Minimumcablerequirements
•Conductors:2x1.5mm²
•Screen:None
•Voltage:60V
•Maximumouterdiameter:N/A
Singlebeamlowpowertransducerconnectiontoacircular
transducersocket
MaximumfoursinglebeamlowpowertransducerscanbeconnectedtosocketsAthrough
Jonthecircular12-pinAmphenoltransducersocket.
ThissocketisusedontheGeneral
PurposeTransceiver(GPT),andonsomeversionsoftheWideBandTransceiver(WBT).
Theotherendofthecableispermanentlyxedtothetransducer.
SimradEK80
