Simrad EK80 Installation Manual

394149/C
85
Thefollowingconsumablesarerequired.
•Solder
•Cablestripsandcableidenticationlabels
•9–pinD-connectorsandcrimpableEthernetconnectors
•ShipcablesandEthernetcables
Note
Wheneverspecicconsumablesorspecialtoolsortestinstrumentsarerequired,these
areidentiedintherelevantprocedure(s).
Note
ItisveryimportantthathighqualityEthernetcablesareused.YoumustuseCAT-5ESTP
(ShieldedTwistedPair)qualityorbetter.Usingcableswithlowerbandwidthcapacity
willreducetheEK80performance.
Generalrequirementsforcableinstallations
Certaingeneralrequirementsapplyforallcableinstallations.
1Refertothecableplanandthelistofcablesforacompleteoverview.
2Detailedinformationaboutcablespecications,terminationandconnectorsare
providedinthereferencedcabledrawings.
3AllcablesareprovidedbyKongsbergMaritimeunlessotherwisespecied.
4Inordertoeasetheaccessformaintenancepurposes,andtoallowforvibration,make
surethatsomeslackisprovidedforeachcable.
5BeforeyoudotheEK80cabling,ensurethattherelevantcircuitbreakersareswitched
off.
6Observethebasiccablerequirements.
Cablelayoutandinterconnections
