394149/C

Topsidecableplan

Thetopside/bridgecablesincludethoseusedtoconnecttheEK80ProcessorUnit(computer)

andthedisplaytoeachother,toACmainspower,andtoexternaldevices.OneEthernet

cableisusedtoconnecttheProcessorUnittotheWideBandTransceiver(WBT).

C8-C1 1

C12-C15

C16

C17

(CD010102_010_001)

ADisplay

BProcessorUnit

CEthernetcommunicationwiththeWideBandTransceiver(WBT)

DEthernetcommunicationwithlocalareanetwork(LAN)

Cablesidentiedwithanasterisk(*)aresystemcables.Theseareprovidedwiththe

standardEK80delivery.

Tip

EventhoughonlyoneEthernetcableisused,werecommendthatyouinstalltwocables

betweentheProcessorUnitandtheWideBandTransceiver(WBT).Thisisrecommended

forredundancypurposes.

Cablelayoutandinterconnections
