Simrad EK80 - About the Drawings in the Drawing File

394149/C
203
Aboutthedrawingsinthedrawingle
Relevantdrawingsrelatedtotheinstallationand/ormaintenanceoftheEK80areprovided
forinformationpurposesonly.
Note
Thesedrawingsareforinformationandplanningpurposesonly.Thedrawingsarenotto
scale.Unlessotherwisespecied,allmeasurementsareinmillimeter(mm).Theoriginal
installationdrawingsareavailableinPDFand/orAutoCad'sDWGformat.Theoriginal
drawingscanbedownloadedfromourwebsite.
•http://www.simrad.com/ek80
Theinstallationshipyardmustprovideallnecessarydesignandinstallationdrawings,as
wellastherelevantworkstandardsandmountingprocedures.
Ifrequired,alldocumentsprovidedbytheshipyardforthephysicalinstallationoftheEK80
mustbeapprovedbythevessel’snationalregistryandcorrespondingmaritimeauthority
and/orclassicationsociety.Suchapprovalmustbeobtainedbeforetheinstallationcan
begin.Theshipownerandshipyarddoingtheinstallationareresponsibleforobtainingand
payingforsuchapproval.
Drawingle
