2Observetheinstallationrequirements.
aThedisplaymustbelocatedsothatitisbestprotectedfromglarewhichreduces
readability.
bThedisplaymaybemountedinapanel,onthedesktoporbulkhead,oroverhead.
cMakesurethatadequateventilationisavailabletoavoidoverheating.
dMakesurethattheinstallationallowsforthephysicalvibration,movementsand
forcesnormallyexperiencedonavessel.
eMakesurethatenoughspaceisprovidedformaintenancework.
3Installthedisplayasdescribedintheapplicabledocumentationprovidedbythe
manufacturer.
4Connectthecables.
Note
Whenyouconnectthecables,makesurethattheyareallproperlysecured,andable
towithstandthevibrationandmovementsofthevessel.
Relatedtopics
Equipmenthandling,page227
Compasssafedistance,page223
Installingacommercialcomputer
TheProcessorUnit(computer)maynotbeincludedwiththeEK80delivery.Ageneric
procedureisthereforeprovided.
Prerequisites
Weassumethatyouareequippedwithastandardsetoftools.Thistoolsetmustcomprise
thenormaltoolsforelectronicandelectromechanicaltasks,suchasscrewdrivers,pliers,
spanners,acablestripperetc.Eachtoolmustbeprovidedinvarioussizes.Werecommend
thatalltoolsaredemagnetizedtoprotectyourequipment.
Asuitablelocationforthecomputermustbedenedpriortoinstallation.
Note
Ifyouplacetheunitonthebridge,observethecompasssafedistance.
