Simrad EK80 Installation Manual

394149/C
9
Aboutthismanual
Purposeofmanual
Thepurposeofthismanualistoprovidetheinformation,proceduresandbasicdrawings
requiredforthephysicalinstallationoftheSimradEK80.
Targetaudience
Themanualisintendedfortechnicalpersonnel;suchasskilledshipyardworkers,
electricians,qualiedengineersandnavalarchitects.Itisassumedthatyouunderstand
thegeneralprinciplesofmaritimeelectronicequipment.Youmustalsobefamiliarwith
computerhardware,interfacetechnologyandinstallationofelectronicandmechanical
products.
Weassumethatyouarefamiliarwiththebasicacousticprinciplesofsoundinwater,and
thatyouhavesomeexperiencewithscienticuseofsonarsand/orechosounders.
Installationinstructions
Youmustfollowtheinstructionsinthismanualtoensureoptimalperformance.Asaguide,
installationproceduresarepresentedintheordertheymustbedone.
Theequipmentdescribedinthismanualincludesthecompletesystemwithrelevant
cabinets.Unitsprovidedlocallybythecustomer,installationshipyardorlocalrepresentative
arenotdescribed.
Themanualalsodenestheequipmentresponsibility,andprovidesapplicableinstructions
forunpackingandstorageofunits.
Note
Youmustfollowtheinstructionsgiveninthismanual.Ifnotitmayaffectthewarranty.
KongsbergMaritimeASwillacceptnoresponsibilityforanydamageorinjurytothesystem,
vesselorpersonnelcausedbyequipmentthathasbeenincorrectlyinstalledormaintained,
orbydrawings,instructionsorproceduresthathavenotbeenpreparedbyus.
