Simrad EK80 - Split Beam Transducer Connection to a Circular Socket

120
394149/C
Minimumcablerequirements
Notapplicable.Ifyouneedanextensioncable,contactyourdealer(orKongsbergMaritime)
forsupport.
Splitbeamtransducerconnectiontoacircularsocket
AsplitbeamtransducerisconnectedtosocketsAthroughJonacircular12-pinAmphenol
transducersocket.ThissocketisusedontheGeneralPurposeTransceiver(GPT),andon
someversionsoftheWideBandTransceiver(WBT).
Theotherendofthecableispermanentlyxedtothetransducer.
M
E
F
J
H
D
C
K
L
A
B
N
FOR WARD
3
4
2
1
H
L
D
A
E
B
F
C
J
M
N
(CD0808_003_008)
A
1
2
4
3
SectorCablecoloursTerminalon
socket
White
H
1
Black
J
Green
E
2
Black
F
Yellow
C 3
Black
D
Blue
A 4
Black
B
ATransducerseenfromtop-
observethesectorlocations
relativetotheforwarddirection!
BSectors
CConnectorsonthe12-pin
Amphenoltransducersocket
DCircular12-pinAmphenol
transducersocketseenfrom
outside
Cablescreen
Screen
N
ThecablescreenmustbeconnectedtothehousingonthetransducerplugandtoterminalN.
