MeasuringnoiseinPassivemode

Lownoiseisakeyfactorforhighqualityandreliablemeasurements.

Prerequisites

ThisprocedureassumesthattheEK80systemhasbeeninstalledasspeciedintheEK80

Installationmanual.

Nospecictoolsorinstrumentsarerequiredforthistest.

Context

ThisprocedureshallverifythatthenoiselevelinPassivemodeisacceptable.

Procedure

1OperateallrelevantfrequenciesinPassivemodewith1,024mspulseduration.

2PreparetheEK80toreadthenoisevalues.

aOntheOperationmenu,clickNormalOperationtoopenthedialogbox.

bIntheNormalOperationdialogbox,setModetoPassive.

cOntheDisplaymenu,clickDisplayOptionstoopenthedialogbox.

dIntheDisplayOptionsdialogbox,enabletheNoisetooltip.

3Placethecursorovertheechogram,andobservethetooltipinformation.

4Readthenoisevaluesforeachchannel.

Writedownthemeasurednoisevalue.
