Simrad EK80 Installation Manual

394149/C
41
Installationsummary
InstallationoftheEK80isademandingtaskthatrequirescarefulpreparations,anumberof
specicprocedures,wiringandrequiredsystemsettings.
Context
Anoverallinstallationprocedureisprovidedbelow.Theproceduredoesnotdescribeany
detailedtasks,butreferstotherelevantproceduresinthismanual.
Note
InordertoobtainmaximumsafetyandEK80performance,itisveryimportantthatthe
installationproceduresinthismanualarecompliedto.Youmustdothetasksintheorder
theyaredescribed.Thevesselownermustmakesurethattheinstallationshipyardholds
theapplicablecompetencetoperformtheinstallation,andthattheapplicablemaritime
authoritiesareavailabletoverifyandcertifytheinstallation.
Procedure
1Basedonthevesseldrawingsandbestpractice,determinewherethetransducer(or
transducers)shallbelocated.
Necessaryconsiderationsmustbetakentoavoidacousticandelectricdisturbances.
Note
Thisinformationinthisdocumentmustberegardedasgeneralguidelinesand
recommendationsonly.
Theinstallationshipyardmustdesignandmanufactureinstallationhardwaretotthe
transducertoeachindividualvessel.Wheneverrequired,theinstallationshipyardmust
alsohavethetransducerinstallationapprovedbytheapplicablemaritimeauthorities.
2Installeachtransducer.
Theinstallationshipyardmustprovideallnecessarydrawingsinordertodothis
installation,andifrequired,thesedrawingsmustbeapprovedbytheapplicable
maritimeauthorities.Eachtransducerwillpenetratethehull,andthisisthereforea
crucialpartoftheEK80installation.
Relevantinstallationdrawingsareincludedwitheachtransducer.Drawingscanalsobe
downloadedfromourwebsite:
•http://www.simrad.com
Preparations
