Simrad EK80 Installation Manual

394149/C
97
Note
DonotusethisEthernetsocket—oranyothersocketsonthecomputer’ smotherboard
—forcommunicationwiththetransceiver .
2ConnectanEthernetcablefromthecomputertotheperipheraldeviceortheship’s
network.
Furtherrequirements
AllEthernetinterfacestoandfromnavigationsensorsmustbedenedintheEK80software
priortouse.
Relatedtopics
RJ45HighspeedEthernetcable(1000Base-t),page117
ConnectingthetransducertotheWideBandTransceiver(WBT)
DependingonyouroperationalrequirementsfortheEK80,oneormoretransducersmustbe
connectedtotheWideBandTransceiver(WBT).
Prerequisites
Youmustbeequippedwithastandardsetoftools.Thistoolsetmustcomprisethenormal
toolsforcableinstallation,suchasdifferentscrewdrivertypes,pliers,acablestripperanda
solderingiron.Eachtoolmustbeprovidedinvarioussizes.Werecommendthatalltools
aredemagnetizedtoprotectyourequipment.Dependingonthetasksathand,additional
toolsmayberequired.
Context
ThetransducerconnectorismountedonthesidepaneloftheWideBandTransceiver
(WBT).Thetransducerconnectorisacircularsocketwith12pinsidentiedasAthroughN.
TheWideBandTransceiver(WBT)usedbytheSimradEK80canbesetuptoworkwith
maximumfour-4-operationalfrequencies.Thismeansthatyoucanusefoursingle
frequency/singlebeamtransducers,twodualfrequencytransducers,oronesplitbeam
transducer.
InordertotakeadvantageoftheadvancedfunctionalityprovidedbytheEK80(size
distribution,shpositionandechoposition),itisnormallysetupwithsplitbeamtransducers.
ThismeansthatoneWideBandTransceiver(WBT)isrequiredforeachtransducer.
Cablelayoutandinterconnections
