394149/C

193

Testingthesynchronizationinterface

Inlargerhydroacousticsystems,theindividualproductsarefrequentlyconnectedtoprovide

transmitsynchronisation.

Prerequisites

ThisprocedureassumesthattheEK80systemhasbeeninstalledasspeciedintheEK80

Installationmanual.

ItisalsoassumedthattheEK80isconnectedtoanexternalhydroacousticsystemfor

triggeringpurposes.

Nospecictoolsorinstrumentsarerequiredforthistest.

Context

Thisprocedureshallverifythattheexternaltriggerinterfaceisoperational.

Note

IftheEK80issetuptooperateasa‘stand-alone’systemindependentofotherhydroacoustic

systems,thistestcanbeomitted.

Procedure

1OntheSetupmenu,clickSynchronizationtoopenthedialogbox.

2Selecttherelevantsynchronizationmode.

3StartboththeEK80andtheexternalsystem,andsetthembothtonormaloperation.

4VerifythattheEK80transmissionsaresynchronizedwiththeexternalsystem.

Settingtowork
