128

394149/C

Minimumcablerequirements

Notapplicable.Ifyouneedanextensioncable,contactyourdealer(orKongsbergMaritime)

forsupport.

SimradES38-18/200-18Cconnectiontoacirculartransducer

socket

TheSimradES38-18/200-18CtransducershallbeconnectedtoterminalsAthroughNona

circular12-pinAmphenoltransducersocket.ThissocketisusedontheGeneralPurpose

Transceiver(GPT),andonsomeversionsoftheWideBandTransceiver(WBT).

FOR WARD

(CD0808_004_001)

SectorCablecoloursTerminalon

socket

White

Black

Green

Black

Yellow

C 3

Black

Blue

4(HF)

Black

DigitaloutputRed

DigitalgroundBlack

ATransducerseenfromtop-

observethesectorlocations

relativetotheforwarddirection!

BSectors

CConnectorsonthe12-pin

Amphenoltransducersocket

DCircular12-pinAmphenol

transducersocketseenfrom

outside

Cablescreen

Screen

ThecablescreenmustbeconnectedtothehousingonthetransducerplugandtoterminalN.
