104

394149/C

MoxaCP114EL-Iconnectors

TheseriallinesareconnectedusingalargeD-connectorontherearsideoftheProcessor

Unitcabinet.

Adapter

Adedicatedadaptercableisprovided

withtheEK80delivery.Itsplitsthelarge

frontmountedconnectortofour9–pin

D-connectors.

Tomaketheindividualconnections

easier,four9-pinD-subconnectorswith

screwterminals,andanumberofadapter

nutsforconnectiontotheadaptercable,

arealsoincludedinthedelivery.

Pinassignments

MoxaCP114EL-I9-pinD-connectorconverter

PinRS-232RS-422RS485(4–wire)RS485(2–wire)

1DCD

TXD-(A)TXD-(A)

RxD

TXD+(B)TXD+(B)

TxD

RXD+(B)RXD+(B)Data-(B)

DTR

RXD-(A)RXD-(A)Data-(A)

GNDGNDGNDGND

6DSR

RTS

8CTS

Relatedtopics

Topsidecableplan,page79
