Simrad EK80 Installation Manual

394149/C
219
Processeddataformats
Thefollowingprocesseddataoutputformatsareavailable.
•None
•XYZ
ThisisprocessedandinterpolatedxyzdatainASCIIformat.Notethatnavigationinput
mustbeavailable.
•EK500
ThisistheproprietaryEK500datagramformat.Thedatagramsconsistsofuserdened
excerptsoftheprocessedsampledata(pixeldata),iethebackscattervalueofthetargets.
Theechogramsarestoredastimetaggeddatagramsinseparateles.
Weightandoutlinedimensions
Theseweightsandoutlinedimensioncharacteristicssummarizethephysicalpropertiesof
theEK80Widebandscienticechosounder.
Note
Formoredetailedinformationaboutthephysicaldimensions,seetheDrawingle.
Display
ThedisplayisnotapartoftheEK80scopeofsupply,anditisnotmanufacturedby
KongsbergMaritime.Refertothedocumentationprovidedbythemanufacturer.
ProcessorUnit
•Makeandmodel:SimradEnix
•Outlinedimensions:
–Depth:385mm
–Width:479.6mm(willtina19"rack)
–Height:177mm
•Weight:16kg(Approximately)
Technicalspecications
